At PCB Power, our PCB Fabrication services epitomize over three decades of industry expertise and innovation. With cutting-edge facilities in both the United States and India, we deliver unrivaled quality and value in every manufacturing endeavor.
At PCB Power, our technical excellence in PCB fabrication is showcased through our comprehensive range of capabilities.
Capability Area |
Specifications & Details |
|---|---|
Materials In Stock |
FR-4 (IPC-4101/21/24/26/124/126) Bergquist Aluminum/Copper Core Polyimide/Kapton (IPC-4101/40) Taconic TSM-DS TLY-5 & DS3 Roger’s 3000/4000/5000/6000 series |
Standard Dielectric Thicknesses |
Ranges from .004 to .125 inches |
Inner Layer Copper Cladding |
Maximum Cu Weight for Planes: 6 oz Maximum Cu Weight for Signals: 4 oz Minimum Cu Weight: .25 oz |
Maximum Panel Size |
24 x 30 inches (22 x 28 inches usable) |
Lamination |
Maximum Layer Count: 22 Maximum Board Thickness: 250 mil Minimum Board Thickness: 5 mil |
Trace and Space |
Inner Layer Minimum Trace & Air Gap: 3 mil for .25 oz Cu to 15 mil for 4 oz Cu Outer Layer Minimum Line/Space: 3 mil for .5 oz Cu to 15 mil for 4 oz+ Cu |
Annular Ring and Clearance |
Outer Layer Annular Ring: > 13 mil over finished hole size Inner Layer Clearance: > 25 mil over finished hole size Thermal Pads: > 15 mil over finished hole size |
Panel Thickness Tolerance |
Precise tolerances to ensure uniformity |
Special technologies |
Flush Circuits Switch Plates Heat Sinks Heavy Copper up to 8 Oz Blind/Buried/Plugged Via Hardware Installation. Selective Gold |
